Λεπτομέρειες προϊόντος
Τόπος καταγωγής: Κίνα Σένζεν
Μάρκα: HSCXLED
Πιστοποίηση: KC CE ROHS FCC CCC ISO9001
Αριθμό μοντέλου: P6.25
Όροι πληρωμής και αποστολής
Ποσότητα παραγγελίας min: 1 σύνοδος
Συσκευασία λεπτομέρειες: Ξύλινη θήκη/κηρήθρα/θήκη αγώνα
Χρόνος παράδοσης: 10-15workdays
Όροι πληρωμής: L/C, T/T, D/A, D/P, Western Union, MoneyGram
Δυνατότητα προσφοράς: 1000set
Όνομα προϊόντος: |
LED διαφανής οθόνη φιλμ |
Εφαρμογή: |
εσωτερική, εξωτερική |
Τύπος: |
Εικονική οθόνη |
λυχνία LED: |
SMD1515 |
Μοντέλο:: |
P6.25 |
Διαπερατό: |
90%~ 95% |
Λάμψη: |
2000-4000 |
Τάση εισόδου: |
AC110-240V50/ 60Hz |
Μέση ισχύος: |
200W/m2 |
Διάρκεια ζωής: |
100000 ώρες |
Όνομα προϊόντος: |
LED διαφανής οθόνη φιλμ |
Εφαρμογή: |
εσωτερική, εξωτερική |
Τύπος: |
Εικονική οθόνη |
λυχνία LED: |
SMD1515 |
Μοντέλο:: |
P6.25 |
Διαπερατό: |
90%~ 95% |
Λάμψη: |
2000-4000 |
Τάση εισόδου: |
AC110-240V50/ 60Hz |
Μέση ισχύος: |
200W/m2 |
Διάρκεια ζωής: |
100000 ώρες |
This New Technology Indoor Transparent LED Film Screen offers high transparency up to 95%, making it ideal for glass curtain walls and retail environments. With a thin profile of just 2.5mm thickness, it supports versatile display functions including video, pictures, text, animation, and cartoons. The product ensures vibrant visuals with brightness levels of 2000/4000 CD/㎡ and a wide viewing angle of 160°. Certified with CCC, KC, CE ROHS FCC, it guarantees compliance with quality and safety standards, enhancing market access for buyers.
The core usage characteristics of LED film screen are light, thin, flexible, high transparency and invisibility, which can adapt to special carriers such as glass curtain walls, and balance display function with the original appearance of the building.
![]()
| Model | P3.75 | P5 | P6 | P8 | P10 | P15 | P20 | P30 |
|---|---|---|---|---|---|---|---|---|
| Pixel pitch | 3.75*3.75mm | 5*5mm | 6.25*6mm | 8.125*8mm | 10*10mm | 15*15mm | 20*20mm | 30*30mm |
| Pixel density | 71,111 Pixels/m² | 40000 Pixels/m² | 26,560 Pixels/m² | 15,375 Pixels/m² | 10,000 Pixels/m² | 4444 Pixels/m² | 2500 Pixels/m² | 1,111 Pixels/m² |
| Module Resolution | 144×64Pixel | 144×48Pixel | 160×40Pixel | 123×30Pixel | 100×24Pixel | 64×16Pixel | 50×12Pixel | 32×8Pixel |
| Module size (W*H*T) |
540mm *240mm |
720mm *240mm |
1000mm *240mm |
1000mm *240mm |
1000mm *240mm |
960mm *240mm |
1000mm *240mm |
960mm* 240mm |
| Weight/pcs | 0.18Kg | 0.2Kg | 0.3Kg | 0.3Kg | 0.3Kg | 0.3Kg | 0.3Kg | 0.3Kg |
| Installation method | Glass direct/clamp tempered glass inner/inner arc installation | |||||||
| Brightness | 1500-2000/3500-4000cd/m² | |||||||
| H/v viewing angle | 140°/140° | |||||||
| Evenness | ≥98% | |||||||
| Highest contrast ratio | 4,000:1 | |||||||
| Protection level | IP43 | |||||||
| Colour | 16bit | |||||||
| Refresh rate | ≥3,840Hz | |||||||
| Change frame frequency | 60Frame /Second Suppot High Resolution3D:120Frame | |||||||
| Screen color temperature | 2,000K~9,500K /Adjustable | |||||||
| Interface | Windows | |||||||
| Working voltage | AC:110V~240V,50~60Hz | |||||||
| Peak power | ≤160W/m² | |||||||
| Average power | 50W/m²~60W/m² | |||||||
| Continuous working hours | ≥7×24h | |||||||
| Mean time between failures | ≥100,000h | |||||||
| Screen temperature rise | ≤3°(during use) | |||||||
| Operating ambient temperature |
-10~60℃ | |||||||
| Operating environment humidity |
10%~90%RH/No condensation | |||||||
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
